Preliminary study of a niobium quarter-wave prototype cavity for a heavy-ion superconducting linac

Abstract
HTML
Reference
Related

PDF

Abstract：

Superconducting quarter-wave resonators, due to their compactness and their convenient shape for tuning and coupling, are very attractive for low-β beam acceleration. In this paper, two types of cavities with different geometry have been numerically simulated：the first type with larger capacitive load in the beam line and the second type of lollipop-shape for 100 MHz, β=0.06 beams；then the relative electromagnetic parameters and geometric sizes have been compared. It is found that the second type, whose structural design is optimized with the conical stem and shaping drift-tube, can support the better accelerating performance. At the end of the paper, some structural deformation effects on frequency shifts and appropriate solutions have been discussed.
