Chinese Physics C > 2010, Vol. 34 > Issue(10): 1665-1670 DOI: 10.1088/1674-1137/34/10/022

A new method to determine the projected coordinate origin of a cone-beam CT system using elliptical projection

Abstract
HTML
Reference
Related

PDF

Abstract：

In order to determine the projected coordinate origin in the cone-beam CT scanning system with respect to the Feldkamp-Davis-Kress (FDK) algorithm, we propose a simple yet feasible method to accurately measure the projected coordinate origin. This method was established on the basis of the theory that the projection of a spherical object in the cone-beam field is an ellipse. We first utilized image processing and the least square estimation method to get each major axis of the elliptical Digital Radiography (DR) projections of a group of spherical objects. Then we determined the intersection point of the group of major axis by solving an over-determined equation set that was composed by the major axis equations of all the elliptical projections. Based on the experimental results, this new method was proved to be easy to implement in practical scanning systems with high accuracy and anti-noise capability.

References

[1]

Ritman E L.Annu.Rev.Biomed.Eng.,2004,6:185-208[2] Lee S C,Kim H K,Chun I K et al.Phys.Med.Biol.,2003,48:4173-4185[3] Feldcamp L A,Davis L C,Kress J W.Opt.Soc.Am.Al,1984,612-619[4] SHU X,Bresler Y.Fast Feldkamp Algorithm for ConeBeam Computer Tomography.Proceedings of International Conference on Image Processing,2003,819-822[5] Gullberg G T,Tsui B M W,Crawford C R et al.Med.Phys.,1990,17:264-272[6] LI J,Jaszczak R J,WANG H,Greer K L et al.Determination of Both Mechanical and Electronic Shifts in Cone Beam SPECT.IEEE Nuclear Science Symposium and Medical Imaging Conference,1992,2:1062-1064[7] Frédéric N,Rolf C,Catherine M et al.Phys.Med.Biol.,2000,45:3489-3508[8] YANG Kai,Kwan A L C,Miller D W F et al.Med.Phys.,2006,33:1695-1706[9] Beque D,Nuyts J,Borrnans G,Suetens P,Dupont P.IEEE Trans.Med.Ima.,2003,22:599-612[10] SUN Yi,HOU Ying,ZHAO Feng-Yong et al.NDTE Int.,2006,39:499-513[11] ZHANG Quan-Hong.Optimization Research on X-ray Industrial CT Imaging.Beijing Univ.of Aeronautics and Astronautics,2005.40-44(in Chinese)[12] YAN Bei,WANG Bin,LI Yuan.Journal of Beijing University of Aeronautics and Astronautics,2008,34:295-298(in Chinese)[13] Kwan A L C,Seibert J A,Boone J M.Medical Physics,2006,33:391-340[14] Altunbas M,Shaw C,CHEN L.Medical Physics,2006,33:2287-2295[15] Richard Van Metter,John Yorkston.SPIE,2001,4320:244-255
