Design and simulation of a wire scanner for the CSNS linac

Abstract
HTML
Reference
Related

PDF

Abstract：

In this paper, we report the design and simulation of a wire scanner for the linac of the CSNS (China Spallation Neutron Source). The wire scanner is used to measure the transverse beam profile and the emittance. The effect of beam energy change upon the mechanical design of the wire scanner must be considered. The simulation results of heat on the two specified wires, tungsten and carbon, by using the finite element method software, ANSYS, are presented. In addition, the effect of wire deformation on the beam profile measurement is qualitatively analyzed, and the signal level of the wire scanner is discussed.
