Investigation on the fabrication of the 3rd harmonic superconducting cavity for the SSRF storage ring

Abstract
HTML
Reference
Related

PDF

Abstract：

A third harmonic superconducting niobium cavity has been proposed for installation in the Shanghai Synchrotron Radiation Facility (SSRF) storage ring to improve the Touschek lifetime. In order to investigate the feasibility of the superconducting cavity fabrication indigenously and the possibility to master the fabrication techniques, cavities were fabricated from copper and niobium sheets by deep drawing and electron-beam welding, and a series of measurements, such as resonant frequency, shape dimensions and wall thickness, were carried out during this process. After analysis of various problems existing in the fabrication process, technique improvements were proposed, and finally the precise shape as designed and resonant frequency within 1.2 MHz were achieved for the new completed cavities. In addition, full annealing was finally proved to be a good cure for niobium sheets' tearing up during deep drawing. By fabricating niobium cavities successfully, some problems to the next step were cleared. This paper introduces the process of cavity fabrication and its technique improvements towards forming, and the initial vertical test result of niobium cavity is also presented.

References

[1]

. ZHAO Z T. Nucl. Sci. Tech, 2003, 14(2): 12. Byrd J M, Georgsson M. Phys. Rev. Special Topics AB,2001, 4: 0307013. Byrd J M, Baptiste K, De Santis S et al. Nucl. Instrum.Methods in Phys. Res. A, 2000, 439: 154. Bosland P, Bredy Ph, Charrier J P et al. Super-3HC Cry-omodule: Layout and First Tests. Paris, France: EPAC.2002. 2217-22195. Kim E S, Sohn Y U, Chun M H et al. Design of a ThirdHarmonic Superconducting RF System at PLS. Lucerne,Switzerland. EPAC. 2004. 2125-21276. Georgsson M, Anders W, Kramer D et al. Nucl. Instrum.Methods in Phys. Res. A, 2001, 469: 3737. Ohkuma H. TOP-UP Operation in Light Sources. Genoa,Italy. EPAC. 2008. 36-408. ZHAO Z T, XU H J, DING H. Genoa, Italy. EPAC. 2008.998-10009. MA G M, ZHAO Z T, LIU J F. Chin. Phys. C (HEP NP), 2008, 32: 27510. HAO Jian-Kui et al. HEP NP, 2001, 25(6): 582 (in Chi-nese)11. Padamsee H, Knoblocn J, Hays T. RF superconductivityfor Accelerators. New York: John Wiley Sons, Inc., 1998.105-12712. Palmieri V. Seamless Superconducting RF Cavities. Pro-ceedings of the Particle Accelerator Conference. New York.1999. 541-54413. Singer W et al. AIP, 2003, 671: 16214. Hartwig K T et al. IEEE Transactions on Applied Super-conductivity, 2007, 17: 130515. Saito K et al. Half-Cell Die Designe for Right Cavity Ge-ometry in High Insity SC Proton Linac. Proceedings of the11th RF Superconductivity Workshop. Travemunde: Ger-many. 2003, 41
