Chinese Physics C > 2009, Vol. 33 > Issue(5): 393-396 DOI: 10.1088/1674-1137/33/5/015

Timing system of HIRFL-CSR

Abstract
HTML
Reference
Related

PDF

Abstract：

The national science project HIRFL-CSR has recently been officially accepted. As a cyclotron and synchrotron complex, it puts some particularly high demands on the control system. There are hundreds of pieces of equipment that need to be synchronized. An integrated timing control system is built to meet these demands. The output rate and the accuracy of the controller are 16 bit/μs. The accuracy of the time delay reaches 40 ns. The timing control system is based on a typical event distribution system, which adopts the new event generation and the distribution scheme. The scheme of the timing control system with innovation points, the architecture and the implemented method are presented in the paper.
