Chinese Physics C > 2009, Vol. 33 > Issue(5): 387-392 DOI: 10.1088/1674-1137/33/5/014

RF system design and measurement of HIRF-CSRe

Abstract
HTML
Reference
Related

PDF

Abstract：

An RF system for the CSRe (cooling storage experimental ring) is designed and
manufactured domestically. The present paper mainly describes the RF system
design in five main sections: ferrite ring, RF cavity, RF generator, low level system and cavity cooling. The cavity is based on a type of coaxial resonator which is shorted at the end with one gap and loaded with domestic ferrite rings. The RF generator is designed in the push-pull mode and the low level control system is based on a DSP+FGPA+DDS+USB interface and has three feedback loops. Finally we give the results of the measurement on our system.
