Radiation response of pseudo-MOS transistors fabricated in hardenedfully-depleted SIMOX SOI wafers

Abstract
HTML
Reference
Related

PDF

Abstract：

The total dose radiation response of pseudo-MOS transistors fabricated in hardened and unhardened FD (fully-depleted) SIMOX (Separation by Implanted Oxygen) SOI (Silicon-on-insulator) wafers is presented. At 1 Mrad(Si) radiation dose, the threshold voltage shift of the pseudo-MOS transistor is reduced from －115.5 to －1.9 V by the hardening procedure. The centroid location of the net positive charge trapped in BOX, the hole-trap density and the hole capture fraction of BOX are also shown. The results suggest that hardened FD SIMOX SOI wafers can perform well in a radiation environment.

References

[1]

Auberton-Herve A J. SOI: Materials to Systems. In: IEEE IEDM technical digest. CA: USA, 1996. 3-102 JenkinsWC, LIU S T. IEEE Trans. Nucl. Sci., 1994, 41(6):23173 Mrstik B J, Gouker P, Lawrence R K et al. IEEE Trans.Nucl. Sci., 2003, 50(6): 19474 Cristoloveanu S, Munteanu D, LIU S T. IEEE Trans. Nucl.Sci., 2000, 47(5): 10185 Hefyene N, Cristoloveanu S, Ghibaudo G et al. Solid-StateElectronics, 2000, 44: 17116 JUN B, Fleetwood D M, Schrimpf R D et al. IEEE Trans.Nucl. Sci., 2003, 50(6): 18917 Sato S, Komiya K, Bresson N et al. IEEE Trans. Nucl. Sci.,2005, 52(8): 18078 Muller R S, Kamins T I. Device Electronics for IntergatedCircuits. New Jersey: John Wiley Publishing Company,1986. 4009 Schwank J R, Ferlet-Cavrois V, Shaneyfelt M R et al. IEEE Trans. Nucl. Sci., 2003, 50(3): 52210 Lawrence R K, Ioannou D E, Hughes H L et al. IEEE Trans.Nucl. Sci., 1995, 42(6): 211411 LIU S T, Jenkins W C, Hughes H L. IEEE Trans. Nucl.Sci., 1998, 45(6): 2442
