Development of a China test cryomodule for ILC

Abstract
HTML
Reference
Related

PDF

Abstract：

Research and development of a 1.3 GHz 9-cell cavity test cryomodule were carried out by a collaboration group between IHEP (Institute of High Energy Physics) and TIPC (Technical Institute of Physics and Chemistry) in China. The cryomodule is a "test model" for the ILC cryomodule, and a key component of a superconducting accelerator test unit which will be built in the near future, also can be used as a horizontal test facility for 1.3~GHz 9-cell cavities. This paper presents the development status of the cryomodule, including structure design, cryogenic flow diagram, thermal and mechanical simulations, heat load estimation and etc.
