Total dose radiation effects on SOI NMOS transistors with different layouts

Abstract
HTML
Reference
Related

PDF

Abstract：

Partially-depleted Silicon-On-Insulator Negative Channel Metal Oxide Semiconductor (SOI NMOS) transistors with different layouts are fabricated on radiation hard Separation by IMplanted OXygen (SIMOX) substrate and tested using 10keV X-ray radiation sources. The radiation performance is characterized by transistor threshold voltage shift and transistor leakage currents as a function of the total dose up to 2.0×10⁶rad(Si). The results show that the total dose radiation effects on NMOS devices are very sensitive to their layout structures.
