A study of radiation effects of 9 and 12MeV protons on Chinese CMOS image sensor degradation

Abstract
HTML
Reference
Related

PDF

Abstract：

The 9 and 12MeV proton irradiations of the Chinese CMOS Image Sensor in the fluence range from 1×10⁹to 4×10×10cm^－2and 1×10⁹to 2×1012cm^－2have been carried out respectively. The color pictures and dark output images are captured, and the average brightness of dark output images is calculated. The anti-irradiation fluence thresholds for 9 and 12~MeV protons are about 4×10¹⁰and 2×10¹²cm^－2, respectively. These can be explained by the change of the concentrations of irradiation-induced electron-hole pairs and vacancies in the various layers of CMOS image sensor calculated by the TRIM simulation program.
