Design and simulation of the wire scanner for the injector linac of BEPCⅡ

Abstract
HTML
Reference
Related

PDF

Abstract：

BEPCⅡ, the upgrade project of Beijing Electron Positron Collider (BEPC), is an accelerator with large beam current and high luminosity, so an efficient and stable injector is required. Several beam diagnostic and monitoring instruments are used. A new diagnostic instrument — wire scanner, has been designed and will be used to measure the profile of the linac beam of BEPCⅡ. This paper describes the prototype of this system and the cause of heat generating of the wire. Some simulation results of the heat and force by using finite element method software—ANSYS^®,2)are presented and discussed.

References

[1]

. Iida N, Suwada T, Funakoshi Y et al. Proceedings of APAC98. Japan, 546-5482. Bailey J L, YANG B X, Buffington T W. Proceedings of PAC 2005. May 16-20, 2005, Knoxville, Tennessee, USA.3667-36693. ValdiviezR et al. Proceedings of PAC2001. June 18-22, 2001Chicago, IL, USA, 1324-13264. XU Ke-Zun. Particle Detection Technology. Shanghai Scientific and Technique Publishers, 1981. 30-32 (in Chinese)5. Hollan F A et al. Heat Transfer. The Design Institute of Jilin Chemical Industry, Translate. Chemical Industry Publisher, 1993. 508-510 (in Chinese)
