Injection system design for a hadron therapy synchrotron

Abstract
HTML
Reference
Related

PDF

Abstract：

A synchrotron is designed for tumour therapy with C⁶⁺ions or proton. Its injector is a cyclotron, which delivers C⁵⁺or H₂⁺ions to the synchrotron. After comparing the methods of the single-turn injection, the multi-turn injection and the stripping injection, this paper chooses the stripping injection method. In addition, the concept design of the injection system is presented, in which the
synchrotron lattice is optimized.
