Chinese Physics C > 2008, Vol. 32 > Issue(5): 385-388 DOI: 10.1088/1674-1137/32/5/012

RF measurements of a C-band cavity beam position monitor

Abstract
HTML
Reference
Related

PDF

Abstract：

RF cold test of a novel C-band cavity beam position monitor (PBM) to be used in the SDUV-FEL Test Facility is described. The test results are presented and some characteristics discussed. The main parameters obtained are in reasonable agreement with the analytical estimations. Effective suppression of the common mode has been demonstrated. The position sensitivity over the test region of ±0.5 mm is about －21.58 dB/10 μm for the TM₁₁₀mode and is linear in the central region of the BPM cavity.

References

[1]

. ZHAO Z T et al. Nucl. Instrum. Methods A, 2004, 528:5912. Emma P. Nucl. Instrum. Methods A, 1999, 429: 4073. Slaton T. Development of Nanometer Resolution C-Band Radio Frequency Beam Position Monitors in the Final Focous Test Beam. In: Proc. of LINAC98. Chicago: 1998.911-9134. CHU Jian-Hua et al. HEP NP, 2006, 30(6): 344 (in Chinese)5. Shintake T. Development of Nanometer Resolution RFBPMs. In: Proc. of HEACC98. Dubna: 1998. 133-1356. Ronald Johnson et al. An X-Band Cavity for a High Precision Beam Position Monitor. In: Proc. of DIPAC2003.Mainz: 2003. 196-198
