Design and studies on the traveling wave transverse RF deflecting structure

Abstract
HTML
Reference
Related

PDF

Abstract：

With the development of free electron laser (FEL) and the international linear collider (ILC), the electron bunch length is getting smaller and smaller. The traveling-wave transverse RF deflecting structure is an important part of the RF deflecting method for bunch length measurement and phase space diagnostics. The operation mode in RF deflector is the ``TM₁₁-like'' mode. Since the TM₁₁-like mode in this structure has a pair of degenerate dipole modes, two additional holes are provided on either side of each iris to stabilize the mode. The simulation and optimization have been done. A prototype has been fabricated and tested. The cold test results have been compared with the simulations of the first three modes.
