Chinese Physics C > 2008, Vol. 32 > Issue(11): 934-938 DOI: 10.1088/1674-1137/32/11/018

Comparison of two position sensitive gamma-ray detectors based on continuous YAP and pixellated NaI(TI) for nuclear medical imaging applications

Abstract
HTML
Reference
Related

PDF

Abstract：

Dedicated position sensitive gamma-ray detectors based on position sensitive photomultiplier tubes (PSPMTs) coupled to scintillation crystals, have been used for the construction of compact gamma-ray imaging systems, suitable for nuclear medical imaging applications such as small animal imaging and single organ imaging and scintimammography. In this work, the performance of two gamma-ray detectors：a continuous YAP scintillation crystal coupled to a Hamamastu R2486 PSPMT and a pixellated NaI(TI) scintillation array crystal coupled to the same PSPMT, is compared. The results show that the gamma-ray detector based on a pixellated NaI(TI) scintillation array crystal is a promising candidate for nuclear medical imaging applications, since their performance in terms of position linearity, spatial resolution and effective field of view (FOV) is superior than that of the gamma-ray detector based on a continuous YAP scintillation crystal. However, a better photodetector (Hamamatau H8500 Flat Panel PMT, for example) coupled to the continuous crystal is also likely a good selection for nuclear medicine imaging applications.

References

[1]

. Garibaldi F, Cisbani E, Cusanno F et al. Nucl. Instrum.Methods A, 2001, 471: 2222. Soares A J, Cullum I, Miller D J et al. IEEE Trans. Nucl.Sci., 2000, 47(3): 10583. Pani R, Pellegrini R, Cinti M N et al. Nucl. Instrum. Methods A, 2006, 569: 2964. Hamamatsu Photomultiplier Tu be Hamamatsu Photonics K.K. Electron Tube Center, Position Sensitive Photomultiplier Tube with Crossed Wire Anodes R2486 Series, Speci cations Manual. Japanese, 19935. Baccaro S, Blazek K, de Notaristefani F et al. Nucl.Instrum. Methods A, 1995, 361: 2096. Pani R, Scafe R, Pellegrini R et al. Nucl. Instrum. Methods A, 2002, 477: 727. CN/ASD Group. PAW Users Guide, nProgram Library Q121. CERN, October 19938. ZHU Jie, LIU Shi-Tao, LEI Xiao-Wen et al. Nuclear Science and Techniques, 2005, 16(4): 2389. ZENG Hai-Ning, XU Zi-Zhong, WANG Zhao-Min et al.HEP NP, 2000, 24(2): 165 (in Chinese)10. Giokaris N, Loudos G, Maintas D et al. Nucl. Instrum.Methods A, 2006, 569: 18511. Pani R, Pellegrini R, Betti M et al. Nucl. Instrum. Methods A, 2007, 571: 475
