Modeling of the RF System for the Normal Conducting Linac

HOU Mi,
PEI Guo-Xi,

Abstract
HTML
Reference
Related

PDF

Abstract：
To study the new RF control methods, a mathematic model of the RF system for the normal conducting Linac is built and implemented with the software of Matlab. The model contains of some typical units of the RF system, such as the klystron, the SLED and the traveling wave accelerating tube. Finally, the model is used to study the working point of the SLED and the adaptive feed forward algorithm for the RF control system. Simulation shows that the model works well as expected.
