Chinese Physics C > 1996, Vol. 20 > Issue(3): 204-210

A Two-Dimensional Poeition Sensitive Multi-Stage Detection System with a Wide Dynamic Range for Heavy Ion Reaction

Institute of Modem Physics, The Chinese Academy of Sciences, Lanzhou 730000

Abstract
HTML
Reference
Related

PDF

Abstract：
A two-dimensional position sensitive multi-stage detection system with a wide dynamic range for heavy ion reaction has been developed. It consists of four parts: a gas filled axial ionization chamber(IC), a position sensitive silicon detector(PSSD)(45×45)mm, 400μm), a large area PIN silicon photodiode(SPD) ((48×48)mm, 300μm) and the 16 element CsI(Tl) scintillation detector. The energy resolutions for IC and PSSD tested with α-source of ²⁴¹Am (5.486MeV) were 3% and 2.6% respectively. Fragments with Z values from Z=2 to Z=21 were identified in the reaction of 25MeV /u ⁴⁰Ar+ ¹¹⁵In. The Z resolving power was Z/△Z≈44.5(FWHM) for Z=18. The position resolution of PSSD was (0.86± 0.03)mm (FWHM).And the energy dynamic range for a particles was about 2-130MeV.

References

[1]

L.Campajola et al,Nucl Instr.and Meth.,A342（1994）534.[2] LIon et al,Nucl Instr and Meth,A325（1993）458.[3] G.Prete et al,Nucl Instr and meth.,A315（1992）109.[4]郭忠言等，T R4终端高性能探测系统，高能物理与核物理，19（1995）865.[5] C.R.Cruhn et al.,Nucl Instr.and Instr.and meth.,196（1982）33.[6] H.W.Fulbright,Nucl Instr.and Meth.,162（1979）21.[7]王金川等，核电子学与探测技术，14（1994）135.[8] Zhan Wenlong et al,Radioactive Ion Beamsat H IR FL,Nucl Phys,to be published.
