RF Measurement and High Power Test of a BNL/KEK/SHI Photocathode RF Gun

Department of Engineering Physics of Tsinghua University, Beijing 100084, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A BNL/KEK/SHI type 1.6cell Photocathode RF gun has been constructed in Tsinghua university. During the tuning process, the relation of the external quality factor to the length of the coupling iris is measured. Mode frequency, single cell frequency and field balance are also measured. Initial high power test results are also presented in this paper.
