Chinese Physics C > 2007, Vol. 31 > Issue(3): 316-319

Magnet and Perturbator Design for a Mini Bremsstrahlung X-Ray Source

DAI Jian-Ping,
GU Xiao-Feng^,

Institute of High Energy Physics, CAS, Beijing 100049, China2 Graduate University of Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A novel X-ray source based on tiny target Bremsstrahlung and tabletop synchrotron was introduced in this paper. It is advantageous in the simple size and low price, perfect in high brilliance and flat spectrum, and it can be used as quasi-point X-ray source. With the help of Poisson Superfish and electron trace program, this paper describes the design method and presents the essential design work for its storage ring and perturbator. The designed magnet satisfies the performance specification, and realizes an effective injection by use of the perturbator.

References

[1]

. Yamada H. Nuclear Instruments and Methods in Physics Research, 2003, B199: 509-5162. Yamada H, Kitazawa Y, Kanai Y et al. Nuclear Instruments and Methods in Physics Research, 2001, A467-468:122-1253. Takeshi Takayama. Nuclear Instruments and Methods in Physics Research, 1987, B24/25: 420-4244. Hammer C L, Bureau A J. Rev. Sci. Instrum., 1955, 26:594-6005. Takayama T. Rev. Sci. Instrum., 1989, 60: 1759-1962
