Chinese Physics C > 2003, Vol. 27 > Issue(6): 546-550

Simulation of Micro-Pulse Electron Guns

Department of Engineering Physics, Tsinghua University, Beijing 100084, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The beam dynamics in micro-pulse electron guns (MPG) is studied using simulation methods in this paper. Based on the working principle of MPGs and the characteristics of its beam dynamics, a multi-particle trace simulation about the three-dimensional movement of the electrons in a MPG cavity is given by a program SEEG (Secondary Electron Emission Gun) written in VC++. The paper includes the principles of simulation and the stability tests of the program SEEG. A specific MPG is simulated using the program SEEG and the simulated beam dynamic results are given.

References

[1]

. Len L K,Mako Frederick M.Self-Bunching Electron Guns.Proc.Particle Accelerator Conf.New York,19992. Mako Frederick M,Peter William. A High-Current Micro-Pulse Electron Gun.Proc.Particle Accelerator Conf.IEEE Cat 93CH379-1,2702,19933. Mako Frederick M,Peter William.European Patent Application.European Patent Office,May21,19974. Guharay S K,Len L K,Mako F.High Current Micro-Pulse Electron Guns and Accelerator Applications.Proceedings of the 2001 Particle Accelerator Conference,Chicago 5. HE Wen-Can,PEI Yun-Ji,JIN Kai et al.High Power Laser and Particle Beams,2001,13(5):615(in Chinese)(何文灿,裴元吉,金凯等.强激光与粒子束,2001,13(5):615)
