Chinese Physics C > 2001, Vol. 25 > Issue(S1): 121-127

Applications for Synchrotron Radiation in Inertial Confinement Fusion Research

National Key Laboratory for Laser Fusion,Research Center of Laser Fusion,CAEP,Mianyang 621900,China1 Institute of High Energy Physics,CAS,Beijing 100039,China

Abstract
HTML
Reference
Related

PDF

Abstract：
In this paper the calibrations of different soft X-ray detector elements used experiment diagnostics of ICF in Beijing Synchrotron Radiation Facility-3W1B beam is reported.SR used special operation type with beam current 35—110mA.the storage ring electron energy 2GeV,photon energy region 50—150eV.First,property of light source was studied by transmission grating-face array CCD system.We have divided 50—1500eV energy region in seven energy section through different material prefilter with monochromaticity better 95%.The AXUV-100 photodiode produced by IRD of America as secondary standard monitored light source intensity.The successive adjust monochromatic light was contained through reflectometer target chamber and relative adjust facility.The sensitivity of XRD(Au,Al),the reflectivity of planar mirror and multi-layer mirror,the transmissivity of different material filter,the diffraction efficiency of transmission grating,the energy response curve of soft X-ray film,the quantum efficiency of face array CCD and the still property of soft X-ray streade camera et al.were calibrated.Finally,the experiment data treatment in Shenguang-Ⅱ were used by many calibration resuite,which secure data treatment accuracy.

References

[1]

YLJ Min. Prospects for Inertial Confenemente Fusion, CAEP-OOOI,HL-0001,1988(in Chinese)(于敏.惯性约束聚变展望，CAEP-0OOI,HL-0001,1988)2 CHANG Tie-Qiang, HE Xian-Tu, YU Min. High Power Laser and Particle Beams, 1989,1(3):193-209(in Chinese)(常铁强，贺贤土，于敏.强激光与粒子束，1989, 1(3):193-209)3 QI Lan-Ying, ZHANG Wen-Hai, LI San-Wei et al. High Power Laser and Particle Beams,l991,3(4):503-511(in Chinese)(祁兰英，张文海，李三伟等.强激光与粒子束，1991，3(4):503-511)4 CUI Min-Qi, LIL1 Li-Bing, XU Wen-Xu et al. High Energy Phys. and Nucl. Phys., 1992,16(8):673-678(in Chinese)(崔明启，刘丽冰，徐文轩等.高能物理与核物理，1992, 16(8):673-678)5 CUI Cong-Wu, CUI Min-Qi, Yl RONG-Qing et al. High Energy Phys. and Nucl. Phys., 1998, 22(2):180-184(in Chinese)(崔聪悟，崔明启，易荣清等.高能物理与核物理，1998, 22(2):180-184)6 Henke B L, Smith J A, Attwood D T. J. App. Phys., 1977, 48(5):18527 Henke B L, Knauer J P, Premaratne K. J. Appl. Phys., 1981, 52(3):15098 Saloman E B. Nuclear Instruments and Methods, 1980, 172:79-87
