Beam Line Design and Construction of Gas Target for a 30MeV Medical Cyclotron

Abstract
HTML
Reference
Related

PDF

Abstract：
The first medical high intensity cyclotron CYCIAE-30 and its beam line for the isotope production were built in 1994 at China Institute of Atomic Energy. Now, an upgrading beam line system is designed based on the existing beam line of CYCIAE-30 to transport the beam extracted from the cyclotron to a gas target for the new isotope production, including elements location design, optics simulation and magnet design. The machining and installation of all the elements are accomplished based on the design. The beam tuning is finished and the transmission of 96.5% is obtained.
