Waveform Sharpening of the Modulator Accelerator

Graduate School of China Academy of Engineering Physics, Beijing 100088, China2 Institute of Applied Electronics, CAEP, Mianyang 621900, China3 Department of Science and Technology, CAEP, Mianyang 621900, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The method which used the spark gap switch to sharpen the output of the modulator accelerator was presented. Through experiments on the pulse modulator accelerator, a rectangular-like waveform with voltage 500kV, pulse width 900ns, rising edge 80ns, trailing edge 100ns is obtained, and repetitive reliable operation is performed at the frequency of 1Hz.
