Research of Distortion and Cooling Method of DCM Crystal

Shanghai Institute of Nuclear Research, the Chinese Academy of Science, Shanghai 201800, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The stress distortion and a cooling method of crystal of double crystal monochromator and its experimental result are reported. The crystal, cooled by this method and exposed to the heat load of total power of 210W and the peak power density of 1.28W/mm ², can be used for bending magnet beam line of Shanghai Synchrotron Radiation Facility.
