Chinese Physics C > 2006, Vol. 30 > Issue(S1): 117-119

New Axial Injection Beam Line of SFC

Institute of Modern Physics, CAS, Lanzhou 730000, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A new axial beam injection system is designed and being constructed at the HIRFL. It consists of 2 GLASSER lenses, 1 dipole, 5 quadrupoles and 3 solenoids. There are two beam line branches for 14.5GHz ECR ion source and 18.5GHz super conducting ECR ion source. Both transverse and longitudinal beam optics are improved in contrast with the old one. The layout, beam optics calculation results and further improved design are given.
