Chinese Physics C > 2004, Vol. 28 > Issue(10): 1109-1115

Design of Accelerating Structure on a Novel Compact Electron Linac

WANG Fa-Ya^,

National Synchrotron Radiation Lab,University of Science and Technology of China,Hefei 230026,China

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper mainly discusses what type of accelerating structure should be chosen for a novel compact electron linac (NCEL for short). After simulation of dynamics process in this linac with Parmela program,we get to the point that it is better on the whole,to choose constant impedance accelerating structure than constant gradient accelerating structure on the NCEL of 10MeV class.In this NCEL,the spent beam of a high power klystron amplifier is used for injecting into an accelerator section and the klystron works in self excited mode of operation. In this paper,the simulations of dynamics process,when the spent beam of a high power 5MW klystron is injected into a constant gradient structure and a constant impedance structure,are carried out. By comparing the output beam performances of these two kinds of structures,one can draw the conclusion that from overall consideration,it will be better to equip the NCEL with constant impedance structure than constant gradient structure,especially when the spent beam of much higher power klystron is used. At the same time the result of simulation indicates that it is unnecessary to use focusing coils around accelerating section,and thus the design will be further simplified for the NCEL.

References

[1]

. XIE Jia-Lin, WANG Fa-Ya et al. RSI, 2003, 74 (12): 5053 —50572. XIE Jia-Lin, WANG Fa-Ya et al. HEP NP, 2004, 28(2): 105 (in Chinese)(谢家麟, 王发芽等. 高能物理与核物理, 2004, 28(2): 105)3. YAO Chong-Guo. Electron Linac, Ch. 2, 4 6. 1986 (in Chinese)(姚充国. 电子直线加速器, 第二、四、六章. 1986)4. Pierre M. Lapostolle and Albert L. Septier. Linear Accelerators. North-Holland Publishing Company, 1970. 1525. DAI Jian-Ping et al. Nuclear Techniques, 2003, 26(7): 497—500 (in Chinese)(戴建枰等. 核技术, 2003, 26(7): 497—500)(in Chinese)(戴建枰等. 核技术, 2003, 26(7): 497-500)6. DONG Dong. Private Communication, IHEP, CAS(in Chinese)(董东提供. 私人通讯, 30MW速调管束流的模拟计算结果, 由 )
