Technological Plan of HLS in SSRF

HE Xiao-Ye^,,
WU Jun

Abstract
HTML
Reference
Related

PDF

Abstract：
The place change of the key inserts, different kinds of magnets for instance, in an accelerator caused by the uneven earth subside will affect the accelerator commission. All accelerator laboratories, at home and abroad have taken the influences more and more seriously. The Shanghai Synchrotron Radiation
Facility (SSRF) under construction is located at Pudong, Shanhai, where geological condition is complicated. It is necessary to establish a monitoring system to monitor the uneven subside of foundation and key parts of the accelerator. The Hydrostatic Leveling System (HLS) is used to real time monitor the vertical displacement of the foundation and the supports of the key inserts in accelerator. This paper discusses the HLS's design plan, the principal parameters and the theoretical calculation. By discussion we can comprehend the importance and necessity to establish HLS in an accelerator in an all-round way.

References

[1]

. HE Xiao-Ye, HUANG Kai-Xi, CHEN Sen-Yu et al. Nucl.Tech., 2007, 30(6): 486-490(in Chinese)(何晓业, 黄开席, 陈森玉等. 核技术, 2007, 30(6), 486-490)2. HE Xiao-Ye, HUANG Kai-Xi, CHEN Sen-Yu et al. Nucl.Tech., 2006, 29(5): 322-325(in Chinese)(何晓业, 黄开席, 陈森玉等. 核技术, 2006, 29(5), 322-325)3. HE Xiao-Ye, HUANG Kai-Xi, CHEN Sen-Yu et al. Journal of Geodesy and Geodymanics, 2007, 27(3): 113-117(in Chinese)(何晓业, 黄开席, 陈森玉等. 大地测量与地球动力学, 2007, 27(3): 113-1174. ZHANG C et al. Primary Hydrokinnetics Study and Experiment on the Hydrostatil levelling System, Procledingsof 27th International Workshop on Accelerator Alignment,2002. Japan. 297-3075. HE Xiao-Ye et al. Data Collection of the Hydrostatic Level-ling System Based on CCD, 2006, 21Suppl.(12): 213-217(in Chinese)(何晓业等. CCD静力水准系统的数据采集, 数据采集与处理, 2006, 21Suppl.(12): 213-217)6. Aschlosser M, Herty A. High Precision Survey and Align-ment of Large Linear Colliders-Vertical Alginment, Proceedings of 7th International Workshop on Accelerator Alignment, Nov.10-14, 2002, Spring-8, Japan. P343-255
