THE COUPLED RESONATOR MODEL AND THE DISTRIBUTION OF THE ELECTRIC FIELD ON THE AXIS IN THE PERIODIC CAVITY CHAIN

CHEN SEN-TU

Instiute of High Energy bo Academia Sinica

Abstract
HTML
Reference
Related

PDF

Abstract：
The Coupled resonator model and the distribution of the electric Field on the axisin the singly periodic cavity chain and biperiodic chain with full-cavity terminationsare analysed by Helmholtz Equation using the symmetry properties of the structure.It is another method to check coupled circuit theory. The results given in this paper forthe singly periodic cavity chain with full- cavity terminations was verified by a 600MHZ linac model of IHEP.
