Experimental Investigation Of repetitive X-band Quasi-Periodic RF Cavity for High Power Microwave Soruce

Institute of Applied Electronics,CAEP,Mianyang 621900,China2 Graduate Department,CAEP,Beijing 100088,China3 Chinese Academy of Engineering Physics,Mianyang 621900,China

Abstract
HTML
Reference
Related

PDF

Abstract：
A novel resonator of quasi-periodic structure is introduced in the paper. On the accelerator CHP-01,its output power and frequency's dependences on system parameters are experimentally investigated. When voltage and current of repetitive diode are 790kV and 6.7kA, respectively, and its repetitive rate is 100Hz,the performance of 1.4GW microwave output power at 9.4GHz microwave frequency with 30ns pulse width and 26\% conversion efficiency are reached.
