Low Level RF Control System for SSRF

Shanghai Institute of Nuclear Research,CAS,Shanghai 201800,China2 Institute of High Energy Physics,CAS,Beijing 100039,China

Abstract
HTML
Reference
Related

PDF

Abstract：
The low level RF control system is an essential part of the RF system for Shanghai Synchrotron Radiation Facility (SSRF). In the R&D of the SSRF, one set of low level control system was developed. It consists of a 500MHz signal generator, three feedback loops, an interlock and a protection system. This paper addresses the design of this system and mainly introduces the three feedback loops.
