Chinese Physics C > 2006, Vol. 30 > Issue(6): 566-570

A Calculation Method for RF Couplers Design Based on Numerical Simulation by Microwave Studio

University of Science and Technology of China,National Synchrotron Radiation Laboratory, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A numerical simulation method for coupler design is proposed. It is based on the matching procedure for the 2π/3 structure given by Dr. R. L. Kyhl. Microwave Studio EigenMode Solver is used for such numerical simulation. The simulation for a coupler has been finished with this method and the simulation data are compared with experimental measurements. The results show that this numerical simulation method is feasible for coupler design.

References

[1]	. Derutyer C K Ng H, Ko K. Numerical Simulation of Cou-pler Cavities of Linacs: SLAC-PUB-6220. April 19932. JIN K. NIM, 2005, 539: 100—1043. WestBrook E. Microwave Impedance Matching of Feed Waveguide to the Disk-loaded Accelerator Structure Operating in the 2π/3 Mode: SLAC-TN-63-103. December1963
