Design and experimental testing of a gas cluster ion accelerator

1.
Key Laboratory of Artificial Micro-and Nano-Materials of Ministry of Education and Hubei Nuclear Solid Physics Key Laboratory, School of Physics and Technology, Wuhan University, Wuhan 430072, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A gas cluster ion beam (GCIB) system with cluster energy up to 12 keV has been designed. To facilitate pumping of the nozzle chamber and increased pressure of the gas source up to 10 atm, pulse mode was used for the gas feeding. Argon was employed as the working gas. To separate monomers from clusters, both electromagnet and retarding electrode were utilized. A maximal pulsed cluster current of 90 nA has been achieved. The shape of pulsed ion beam currents has been analyzed in detail at different applied magnetic and retarding electric fields.
- gas cluster ion beam,
- flow visualization,
- cluster mass separation,
- retarding electrode

References

[1]	I. Yamada, J. Matsuo, N. Toyoda et al, Mater Sci. Eng. R, 34:231 (2001)
[2]	T. Yamaguchi, J. Matsuo, M. Akizuki et al, Nucl. Instr. Meth. B, 99:237 (1995)
[3]	N. Toyoda, H. Kitani, N. Hagiwara et al, Mater. Chem. Phys., 54:262 (1998)
[4]	A. Kirkpatrick, Nucl. Instr. Meth. B, 206:830 (2003)
[5]	H. Chen, F. Chen, X. M. Wang et al, Appl. Phys. Lett., 87:103504 (2005)
[6]	J.-H. Song, D.-K. Choi, W.-K. Choi, Nucl. Instr. Meth. B, 196:275 (2002)
[7]	K. Ichiki, S. Ninomiya, Y. Nakata et al, Appl. Surf. Sci., 255:1148 (2008)
[8]	T. Kitagawa, I. Yamada, N. Toyoda et al, Nucl. Instr. Meth. B, 201:405 (2003)
[9]	N. Toyoda, I. Yamada, Surf. Coat. Tech., 201:8620 (2007)
[10]	T. Seki, J. Matsuo, Nucl. Instr. Meth. B, 237:455 (2005)
[11]	E. W. Becker, K. Bier, and W. Henkes, Z. Physik, 146:333 (1956)
[12]	O. F. Hagena, W. Obert, Chem. Phys., 56:1793 (1972)
[13]	J. Matsuo, H. Abe, G. H. Takaoka et al, Nucl. Instr. Meth. B, 99:244 (1995)
[14]	A. Kirkpatrick and J. Greer, AIP Conf. Proc., 475:405 (1999)
[15]	M.E. Mack, AIP Conf. Proc., 576:991 (2001)
[16]	N. Toyoda, J. Matsuo, I. Yamada, Nucl. Instr. Meth. B, 216:379 (2004)
[17]	A. A. Andreev, V. S. Chernysh, Y. A. Ermakov et al, Vacuum, 91:47 (2013)
[18]	G. Tejeda, B. Mate, J. M. Fernandez-Sanchez et al, Phys. Rev. Lett., 76:34 (1996)
[19]	N. G. Korobeishchikov, V. V. Kalyada, P. A. Skovorodko et al, Vacuum, 119:256 (2015)
[20]	A. Ieshkin, Y. Ermakov, V. Chernysh et al, Nucl. Instr. Meth. A, 795:395 (2015)
