Chinese Physics C > 2017, Vol. 41 > Issue(8): 087001 DOI: 10.1088/1674-1137/41/8/087001

Focusing properties of discrete RF quadrupoles

Zhi-Hui Li^1,,,
Zhi-Jun Wang²

1.
The Key Laboratory of Radiation Physics and Technology of Ministry of Education, Institute of Nuclear Science and Technology, Sichuan University, Chengdu 610065, China
2.
Institute of Modern Physics, Chinese Academy of Sciences, Lanzhou 730000, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The particle motion equation for a Radio Frequency (RF) quadrupole is derived. The motion equation shows that the general transform matrix of a RF quadrupole with length less than or equal to 0.5 β λ( βis the relativistic velocity of particles and λis wavelength of radio frequency electromagnetic field) can describe the particle motion in an arbitrarily long RF quadrupole. By iterative integration, the general transform matrix of a discrete RF quadrupole is derived from the motion equation. The transform matrix is in form of a power series of focusing parameter B. It shows that for length less than β λ, the series up to the 2 ^ndorder of Bagrees well with the direct integration results for Bup to 30, while for length less than 0.5 β λ, the series up to 1 ^storder is already a good approximation of the real solution for Bless than 30. The formula of the transform matrix can be integrated into linac or beam line design code to deal with the focusing of discrete RF quadrupoles.
- RF quadrupole,
- transform matrix,
- focusing parameter,
- iterative integration,
- hybrid RFQ

References

[1]	U. Ratzinger, In Proceedings of the 1988 Linac Conference, (Virginia, USA, 1988) p. 185
[2]	P. N. Ostroumov, A. A. Kolomiets, S. Sharma et al, Nuclear Instruments and Methods in Physics Research A, 547:259-269 (2005)
[3]	Zhi-Jun Wang, Yuan He, A. A. Kolomiets et al, Chinese Physics C, 37(12):127001 (2013)
[4]	N. W. McLachlan, Theory and application of Mathieu functions, (Amen House, London E.C.4, Oxford University Press, 1951)
[5]	K. R. Crandal, R. H. Stokes, T. P. Wangler, In Proceedings of 1979 Linac Conference p205
[6]	T. P. Wangler, Principles of RF linear accelerators, (John wiley sons, Inc., New York, 1998) P189
