Chinese Physics C > 2017, Vol. 41 > Issue(7): 078101 DOI: 10.1088/1674-1137/41/7/078101

Preliminary study of EEHG-based superradiant undulator radiation at the HLS-II storage ring

1.
College of Mathematics and Physics, Fujian University of Technology, Fuzhou 350118, China
2.
National Synchrotron Radiation Laboratory, University of Science and Technology of China, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
We investigate storage ring-based Echo-Enabled Harmonic Generation (EEHG) superradiant undulator radiation as a possible scheme to obtain shorter wavelengths at the HLS-II (Hefei Light Source-II) storage ring. In this paper we give the designation of the storage ring based EEHG up to the 26th harmonic, where 31 nm vacuum ultraviolet light is radiated from an 800 nm seeded laser. The novelty of our design is that both the two dispersion sections of EEHG are realized by the storage ring's own magnet structure. In particular, the whole ring is used as the first dispersion section, and two modulators of the traditional EEHG can be done with the same undulator. These two dispersion sections are realized by changing the superperiod of the present lattice structure, and more precisely by changing the focusing strengths of the present structure. Since no additional magnets and chicanes are used, the beam circulates around the storage ring repeatedly, and thus this storage ring-based EEHG can have a higher repetition rate than a linac-based EEHG.
- storage ring,
- EEHG,
- lattice

References

[1]	D. Xiang, E. Colby, M. Dunning, et al, Phys. Rev. Lett., 108: 024802 (2012)
[2]	G. Stupakov. Phys. Rev. Lett., 102: 074801 (2009)
[3]	D. Xiang, E. Colby, M. Dunning et al, Phys. Rev. Lett., 105: 114801 (2010)
[4]	E. Hemsing, M. Dunning, C. Hast et al, Phys. Rev. ST Accel. Beams, 17: 070702 (2014)
[5]	E. Hemsing, M. Dunning, B. Garcia et al, Nature Photon., 101: 1-4 (2016)
[6]	Z. T. Zhao, D. Wang, J. H. Chen et al, Nature Photon., 6: 360-363 (2012)
[7]	R. Molo, M. Hm ner, H. Huck et al, EEHG and Femtoslicing at DELTA, Proceedings of FEL2013, New York, NY, USA (2013)
[8]	C. Evain, M. E. Couprie, J. M. Filhol et al, Study of High Harmonic Generation at Synchrotron SOLEIL Using Echo Enabling Technique, Proceedings of IPAC10, Kyoto, Japan (2010)
[9]	J. Krzywinski, J. T. Delor, P. A. Montanez et al, Design Challenge and startegy for the LCLS-Ⅱ high repetition rate X-ray FEL photon stoppers, Proceedings of FEL2015, Daejeon, Korea (2015)
[10]	G. West and R. Coffee, Optical Tailoring of xFEL beams, SLAC-TN-15-090
[11]	W. W. Gao, L.Wang, W. Li, Phys. Rev. ST Accel. Beams, 14: 094001 (2011)
[12]	M. Borland, Users manual for elegant program version 29.1.0.
[13]	Y. H. Cai, Theory of Microwave instability and coherent synchrotron radiation in electron storage rings, Proceedings of IPAC2011, San Sebastin, Spain (2011)
[14]	H. Wiedemann, Particle accelerator physics, Springer, 1999
[15]	H. T. Li, Y. L. Lu, Z. G. He et al, J Infrared Milli Terahz Waves, 37: 649-657 (2016)
[16]	Dao Xiang and Gennady Stupakov, Phys. Rev. ST Accel. Beams, 12: 030702 (2009)
[17]	Zhirong Huang and Kwang-Je Kim, Phys. Rev. ST Accel. Beams, 5: 074401 (2002)
[18]	Private communication with Yokoya
