Study of TTS for a 20-inch dynode PMT

1.
Guangxi Key Laboratory for Relativistic Astrophysics, Guangxi University, Nanning 530004, China
2.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
3.
University of Chinese Academy of Science, Beijing 10049,China
4.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
5.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The neutrino detector for the Jiangmen Underground Neutrino Observatory (JUNO) requires a large number of photomultiplier tubes (PMTs), including 15000 MCP PMTs and 5000 dynode PMTs. The TTS (transit time spread) of the PMTs is very important for vertex and track reconstruction of the neutrinos in the detector. In this paper, we study the TTS of a 20-inch dynode PMT (R12860) from Hamamatsu for different high voltage, light intensity, light spot size and different photocathode regions. The impact from Earth's magnetic field is also studied. The results achieved in this paper will be very useful for the JUNO experiment.
