Chinese Physics C > 2016, Vol. 40 > Issue(8): 086003 DOI: 10.1088/1674-1137/40/8/086003

Setup of a photomultiplier tube test bench for LHAASO-KM2A

1.
School of Physics and Key Laboratory of Particle Physics and Particle Irradiation (MOE), Shandong University, Jinan 250100, China

Abstract
HTML
Reference
Related

PDF

Abstract：
To fulfill the requirements for testing the photomultiplier tubes (PMTs) of the electromagnetic detector at the Large High Altitude Air Shower Observatory (LHAASO), a multi-functional PMT test bench with a two-dimensional scanning system has been developed. With this 2D scanning system, 16 PMTs can be scanned simultaneously for characteristics tests, including uniformity, cathode transit time difference, single photo-electron spectrum, gain vs. high voltage, linear behavior and dark noise. The programmable hardware and intelligent software of the test bench make it convenient to use and provide reliable results. The test methods are described in detail and primary results are presented.
- PMTs,
- LHAASO,
- KM2A,
- SPE spectrum,
- cathode uniformity,
- TTS,
- CTTD

References

[1]	H.H.He et al (the LHAASO Collaboration), in Proceedings of 31th ICRC (2009)
[2]	Z. Cao, Chinese Physics C, 34 (2): 249-252 (2010)
[3]	J. Zhao et al, Chinese Physics C, 38 (3): 31-38 (2014)
[4]	X. Wang, C. J. Li, H. J. Wu et al, Nuclear Electronics Detection Technology, 2: 200-203 (2014) (in Chinese)
