Study on transient beam loading compensation for China ADS proton linac injector Ⅱ

1.
Institute of Modern Physics, Chinese Academy of Sciences, Lanzhou 730000, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100049, China
3.
Institute of Modern Physics, Chinese Academy of Sciences, Lanzhou 730000, China
4.
Thomas Jefferson National Accelerator Facility, Newport News, VA 23606, USA

Abstract
HTML
Reference
Related

PDF

Abstract：
Significant transient beam loading effects were observed during beam commissioning tests of prototype Ⅱ of the injector for the accelerator driven sub-critical(ADS) system, which took place at the Institute of Modern Physics, Chinese Academy of Sciences, between October and December 2014. During these tests experiments were performed with continuous wave(CW) operation of the cavities with pulsed beam current, and the system was configured to make use of a prototype digital low level radio frequency(LLRF) controller. The system was originally operated in pulsed mode with a simple proportional plus integral and deviation(PID) feedback control algorithm, which was not able to maintain the desired gradient regulation during pulsed 10 mA beam operations. A unique simple transient beam loading compensation method which made use of a combination of proportional and integral(PI) feedback and feedforward control algorithm was implemented in order to significantly reduce the beam induced transient effect in the cavity gradients. The superconducting cavity field variation was reduced to less than 1.7% after turning on this control algorithm. The design and experimental results of this system are presented in this paper.
