Development of a high-power and ultra-high-vacuum waveguide coupler working at C/X band

Abstract
HTML
Reference
Related

PDF

Abstract：
Waveguide directional couplers working at 5.712/11.9924 GHz are developed. Even holes symmetrical to the structure are drilled along the central line of the narrow-wall of the waveguide, which are used to couple the electromagnetic power from the main-waveguide to the sub-waveguide. The final prototypes have achieved satisfactory performances of high-power, ultra-high-vacuum and high-directivity. The microwave measurement results are also qualified.
