Electron gun system for NSC KIPT linac

Abstract
HTML
Reference
Related

PDF

Abstract：
In the NSC KIPT linac, a neutron source based on a subcritical assembly driven by a 100 MeV/100 kW electron linear accelerator is under design and development. The linear accelerator needs a new high current electron gun. In this paper, the physical design, mechanical fabrication and beam test of this new electron gun are described. The emission current is designed to be higher than 2 A for the pulse width of 3 μs with repetition rate of 50 Hz. The gun will operate with a DC high voltage power supply that can provide a high voltage up to 150 kV. Computer simulations and optimizations have been carried out in the design stage, including the gun geometry and beam transport line. The test results of high voltage conditioning and beam test are presented. The operation status of the electron gun system is also included. The basic test results show that the design, manufacture, and operation of the new electron system are basically successful.

References

[1]

CHI Yun-Long et al. Design Report on the NSC KIPT Electron Linear Accelerator, Version 2, IHEP, 2011.8[2] ZHOU Z et al. Desing Studies on NSC KIPT Electron Gun System. IPAC2013. Shanghai, China, 2013. 2768-2770[3] Herrmannsfeldt W B. EGUN - an Electron Optics and Gun Design Program. SLAC-331, 1988[4] PEI Shi-Lun et al. Beam Dynamic Studies on the 100 MeV/ 100 kW Electron Linear ACCELERATOR for NSC KIPT Neutron Source. IPAC2011. San Sebastian, Spain, 2011. 673-675[5] Chi Y et al. Progress on the Construction of the 100 MeV/ 100 kW Electron LINAC for the NSC KIPT Neutron Source. IPAC2013. Shanghai, China, 2013. 351-353
