Chinese Physics C > 2014, Vol. 38 > Issue(6): 067003 DOI: 10.1088/1674-1137/38/6/067003

Beam dynamics studies of the photo-injector in low-charge operation mode for the ERL test facility at IHEP

Abstract
HTML
Reference
Related

PDF

Abstract：
The energy recovery linac test facility (ERL-TF), which is a compact ERL-FEL (free electron laser) two-purpose machine, was proposed at the Institute of High Energy Physics, Beijing. As one important component of the ERL-TF, the photo-injector that started with a photocathode direct-current gun has been designed. In this paper, optimization of the injector beam dynamics in low-charge operation mode is performed with iterative scans using Impact-T. In addition, the dependencies between the optimized beam quality and the initial offset at cathode and element parameters are investigated. The tolerance of alignment and rotation errors is also analyzed.
