Chinese Physics C > 2014, Vol. 38 > Issue(3): 037002 DOI: 10.1088/1674-1137/38/3/037002

Physical design of superconducting magnet for ADS injection Ⅰ

Abstract
HTML
Reference
Related

PDF

Abstract：
A superconducting solenoid prototype magnet for Accelerator Driven Subcritical System (ADS) Injection Ⅰ has been designed and fabricated, which has also been tested in a liquid Helium state inside a vertical Dewar in the Haerbin institute of Technology in November 2012. The design current was 210 A, when the test current reached 400 A no quench occurred so the solenoid magnet was forced to quench by the embedded heaters. The integral field strength, leakage field at the nearby upstream and downstream superconducting spoke cavities all meet the design requirements. At the same time, it also checked the reliability of the vertical test Dewar and the quenched detection system. The superconducting prototype magnet has accumulated valuable experiences for the coming batch magnets production and cryogenic test.

References

[1]

Future Advanced Nuclear Fission Energy-Plan Implement Book for ADS Evolution System (in Chinese), 2010[2] Opera Manager User Guide (manual), Version 14R1, Vector Fields Software, July 2011[3] GREEN M A, WITTE H. Quench Protection and Magnet Power Supply Requirements for the MICE Focusing and Coupling Magnets. Oxford Physics Engineering Report 15, LBNL-57580, 2005
