Measurement of X-ray photon energy and arrival time using a silicon drift detector

Abstract
HTML
Reference
Related

PDF

Abstract：
Detecting the X-ray emission of pulsars and obtaining the photons' time of arrival are the foundational steps in autonomous navigation via X-ray pulsar measurement. The precision of a pulse's time of arrival is mainly determined by the precision of photon arrival time measurement. In this work, a silicon drift detector is used to measure photon energy and arrival time. The measurement system consists of a signal detector, a processing unit, a signal acquisition unit and a data receiving unit. This system acquires the energy resolution and arrival time information of photons. In particular, background noise with different energies disturbs pulse profile forming, the system can also achieve a high signal-to-noise ratio profile. Ground test results show that this system can be applied in autonomous navigation based on X-ray pulsar measurement.

References

[1]

Voges W, Aschenbach B, Boner T et al. ROSAT All-sky Survey Faint Source Catalogue. International Astronomical Union Circular, 2000, 7432[2] Sheikh S I, Pines J D. Journal of Guidance, Control, and Dynamics, 2006, 19: 49-63[3] Emadzadeh A A, Speye J L, Hadaegh F Y. A Parametric Study of Relative Navigation using Pulsars. Proceedings of ION 63rd Annual Meeting Cambridge, USA. 2007[4] Graven P H, Collins J T, Suneel I S et al. Spacecraft Aviation Using X-Ray Pulsars. 7th International ESA Conference on Guidance, Navigation Control Systems. County Kerry, Ireland, 2008[5] Wood K S, Determan J R, Ray P S et al. Using the Unconventional Stellar Aspect (USA) Experiment on ARGOS to Determine Atmospheric Parameters by X-ray Occultation. Proceedings of SPIE-The International Society for Optical Engineering. USA: SPIE, 2002[6] HU Hui-Jun, ZHAO Bao-Sheng. Acta Phys. Sin., 2012, 61(1): 1-7[7] ZHANG Fei, WANG Huan-Yu, PENG Wen-Xi et al. CPC (HEP NP), 2012, 36(2): 146-150[8] Lechner P, Eckbauer S, Hartmann R et al. Nuclear Instruments and Methods in Physics Research, 1996, 377: 346-351[9] Nouais D, Beole S, Bondila M et al. Nuclear Instruments and Methods in Physics Research, 2003, 501: 119-125[10] ZHENG Wei, SUN Shou-Ming. China Patent, ZL201010022035.7 2012 (in Chinese)
