Design and implementation of the NaI(Tl)/CsI(Na) detectors output signal generator

Abstract
HTML
Reference
Related

PDF

Abstract：
We designed and implemented a signal generator that can simulate the output of the NaI(Tl)/CsI(Na) detectors' pre-amplifier onboard the Hard X-ray Modulation Telescope (HXMT). Using the development of the FPGA (Field Programmable Gate Array) with VHDL language and adding a random constituent, we have finally produced the double exponential random pulse signal generator. The statistical distribution of the signal amplitude is programmable. The occurrence time intervals of the adjacent signals contain negative exponential distribution statistically.

References

[1]

ZHANG Y F. Performance Study of the Hard X-ray Detector on HXMT (PhD thesis). Institute of High Energy Physics, 2011 (in Chinese)[2] YU Q L. Development of the TestSystem for HES of HXMT (Master thesis). Tsinghua University, 2010 (in Chinese)[3] WANG L J. Technical Development of Random Pulse Generator Simulated Nuclear Signal (Master thesis). University of South China, 2007 (in Chinese)[4] WANG SH G, ZHOU Z Y. X-ray Astronomy Physics. Beijing: Science Press, 1999 (in Chinese)[5] CHEN B X, ZHANG Z H. Nuclear Radiation Physics Detection. Harbin: Harbin Institute of Technology Press, 2011 (in Chinese)[6] Bloser P F et al. arXiv: astro-ph/9910244[7] LIN ZH H. Modern Electronics Technique, 2009, 32(9): 49 (in Chinese)
