Chinese Physics C > 2014, Vol. 38 > Issue(10): 107004 DOI: 10.1088/1674-1137/38/10/107004

Field measurement for superconducting magnets of ADS injector Ⅰ

Abstract
HTML
Reference
Related

PDF

Abstract：
A superconducting magnet prototype for Accelerator Driven Sub-critical System Injection-Ⅰ had been designed and fabricated, and tested in a new made vertical Dewar in November 2012. Batch magnet production was processed after some major revision from the magnet prototype, they include: removing off the perm-alloy shield, extending the iron yoke, using thin superconducting wire, etc. The first one of the batch magnets was tested in the vertical Dewar at the Harbin Institute of Technologyin in September 2013. A field measurement was carried out at the same time by the measurement platform that was seated on the top of the vertical Dewar，the measurement results met the design requirements. This paper will present the field measurement system design, measurement results and discussion on the residual field from the persistent current effect.

References

[1]

Zeller A F et al. IEEE Transaction on Applied Superconductivity, 2002, 12: 329[2] YAN Fang, LI Zhi-Hui, MENG Cai et al. Chinese Physics C, 2014, to be published[3] PENG Quan-Ling, WANG Bing, CHEN Yuan et al. Chinese Physics C, 2014, 38: 037002[4] Tartaglia M A, Burkhardt E, Leach T et al. IEEE Transaction on Applied Superconductivity, 2010, 20: 312[5] Turner S. CERN Accelerator School Superconductivity in Particle Accelerators. 1989, CERN 89-04[6] PENG Q L, McMurry S M, Coey J M D. Journal of Magnetism and Magnetic Material, 2004, 268: 165[7] Opera Manager User Guide. Version 14R1, Vector Fields Software. July 2011
