Application of a wedge strip anode in micro-pattern gaseous detectors

Abstract
HTML
Reference
Related

PDF

Abstract：
The wedge strip anode (WSA) has been widely used in 2-D position-sensitive detectors. A circular WSA with an effective diameter of 52 mm is successfully coupled to a tripe gas electron multiplier (GEM) detector through a simple resistive layer. A spatial resolution of 440 μm (FWHM) is achieved for a 10 kVp X-ray using 1 atm Ar: CO ₂=70:30 gas. The simple electronics of only three channels makes it very useful in applications strongly requiring simple interface design, e.g. sealed tubes and high pressure detectors.

References

[1]

Anger H O. Instrum. Soc. Am. Trans., 1966, 5: 311[2] Smith A et al. Rev. Sci. Instrum., 1989, 60: 3509-3518[3] Lapington J S et al. Nucl. Instrum. Methods A, 2003, 513: 161[4] Dixit M S, Rankin A. Nucl. Instrum. Methods A, 2006, 566: 282[5] XIE Yi-Gang et al. Particle Detector and Data Acquisition. Beijing: Science Press, 2003. 42-43 (in Chinese)[6] Siegmund O H W et al. IEEE Trans. Nucl. Sci., 1986, 33: 725
