Chinese Physics C > 2013, Vol. 37 > Issue(3): 037001 DOI: 10.1088/1674-1137/37/3/037001

Beam transmission efficiency of the HIRFL-SSC

YE Feng^,,
YANG Shang-Yun

Abstract
HTML
Reference
Related

PDF

Abstract：
In this paper we address the problem of the low beam transmission efficiency of the HIRFL-SSC. The influence of the SFC-SSC energy match, the SSC RF voltage, and harmonic field in the injection area of the SSC, and the SSC central trajectory on the beam transmission efficiency have been analyzed both from the theoretical side and from the actual operating data. The main reason is that the soft-edge approximation of the magnet field (the so-called theoretical field) and the simplified calculation programs were adopted when calculating the beam center trajectory and designing the injection and extraction system, and the measured magnetic field was not used to correct the calculation results. These led to large deviations of the calculated center trajectory, and then resulted in low efficiency of the SSC beam transmission. Therefore, the re-calculation of SSC beam center trajectory and injection and extraction system, as well as the measured magnet field correction are the key points required to solve the problem.

References

[1]

DING Yuan-Tao. Study of beam properties of SSC, Institute of Modern Physics, Chinese Academy master's degree graduate degree thesis 2001[2] LI Xiao-Ni, YUAN You-Jin et al. High Power Laser and Particle Beams, 2010 22(9): 2133-2137[3] HAO Huan-Feng, ZHAO Hong-Wei, YANG Yi-Ping et al. Proceedings of CYCLOTRONS 2010, Lanzhou, China MOPCP102, 2010[4] HAO Huan-Feng. Latest research of SSC injection efficiency, Internal data of IMP, 2010
