Chinese Physics C > 2013, Vol. 37 > Issue(2): 026002 DOI: 10.1088/1674-1137/37/2/026002

Study of 2D interpolating readout for a micro-pattern gaseous detector

Abstract
HTML
Reference
Related

PDF

Abstract：
The two-dimensional interpolating readout, a new readout concept based on resistive anode structure, was studied for the micro-pattern gaseous detector. Within its high spatial resolution, the interpolating resistive readout structure leads to an enormous reduction of electronic channels compared with pure pixel devices, and also makes the detector more reliable and robust, which is attributed to its resistive anode relieving discharge. A GEM (gaseous electron multiplier) detector with 2D interpolating resistive readout structure was set up and the performance of the detector was studied with ⁵⁵Fe 5.9 keV X-ray. The detector worked stably at the gain up to 3.5×10 ⁴without any discharge. An energy resolution of about 19%, and a spatial resolution of about 219 μ (FWHM) were reached, and good imaging performance was also obtained.

References

[1]

Sauli F. Nucl. Instrum. Methods A, 1997, 386(2-3): 531[2] Chechik R, Breskin A, Shalem C et al. Nucl. Instrum. Methods A, 2004, 535(1-2): 303[3] Giomataris Y, Rebourgeard Ph, Robert J P et al. Nucl. Instrum. Methods A, 1996, 376(1): 29[4] Besch H J, Junk M, Meiβner W et al. Nucl. Instrum. Methods A, 1997, 392(1-3): 244[5] Sarvestani A, Besch H J, Junk M et al. Nucl. Instrum. Methods A, 1998, 419(2-3): 444[6] Orthen A, Wagner H, Besch H J et al. Nucl. Instrum. Methods A, 2002, 478(1-2): 200[7] Wagner H, Besch H J, Menk R H et al. Nucl. Instrum. Methods A, 2002, 482(1-2): 334[8] L Xin-Yu, FAN Rui-Rui, CHEN Yuan-Bo et al. CPC (HEP NP), 2012, 36(3): 228
