Chinese Physics C > 2012, Vol. 36 > Issue(8): 756-760 DOI: 10.1088/1674-1137/36/8/013

Mitigating the effects of higher order multipole fields in the magnets of the Accelerator Test Facility 2 at KEK

Abstract
HTML
Reference
Related

PDF

Abstract：
The ATF2 project is the final focus system prototype for the ILC and CLIC linear collider projects, with the purpose of reaching a 37nm vertical beam size at the interaction point. In the nanometer beam size regime, higher order multipoles in magnets become a crucial point for consideration. The strength and rotation angle of the ATF2 QEA magnets were reconstructed from the IHEP measurements and compared with the KEK ones to be identical. Based on the study of the skew multipoles sensitivity, we report on the analysis of the possible mitigation of the measured multipoles. A suggestion is given which will benefit the ATF2 present commissioning to reach the goal beam size, and also the reduced β optics in future.

References

[1]

Grishanov B I et al. 2005, Report No. SLAC-R-771[2] Bambade P et al. Phys. Rev. ST Accel. Beams, 2010, 13: 042801[3] ILC RDR, ILC-Report-2007-001[4] Masuzawa M, Sugahara R. IEEE Transations on Applied Superconductivity, 2010, 20(3): 1969-1972[5] Tomas R et al. PAC09 WE6PFP024[6] Cherrill S. 2010, Report No. SLAC-PUB-14339[7] Iselin F C. 1985, CERN LEP-TH No. 85-15[8] Marin E et al. 2011, CERN-ATS-2011-122
