Development of the relativistic backward wave oscillator with a permanent magnet

Abstract
HTML
Reference
Related

PDF

Abstract：
Firstly, an X-band relativistic backward wave oscillator with a low guiding magnetic field is simulated, whose output microwave power is 520 MW. Then, an experiment is carried out on an accelerator to investigate a relativistic backward wave oscillator with a permanent magnetic field whose strength is 0.46 T. When the energy of the electron is 630 keV and the current of the electron beam is 6.7 kA, a 15 ns width pulsed microwave with 510 MW output power at 8.0 GHz microwave frequency is achieved.

References

[1]

Gunin V et al. IEEE Trans. P. S., 1998, 26(3): 173-177[2] MA Qiao-Sheng, LIU Qing-Xiang, SU Chang. HEP NP, 2003, 27(6): 542-545 (in Chinese)[3] MA Qiao-Sheng, LI Zheng-Hong, MENG Fan-Bao. HEP NP, 2005, 29(10): 1002-1005 (in Chinese)[4] LIU Guo-Zhi, CHENG Chang-Hua, ZHANG Yu-Long. High Power Laser and Particle Beams, 2001, 13(4): 467-470 (in Chinese)[5] Vladimir P. Tarakanov. User's Manual for Code KARAT, Ver.8.17, 2004. Berkeley Research Associates, Inc. 2004[6] MA Qiao-Sheng, FAN Zhi-Kai, ZHOU Chan-Ming. Chinese Physics C (HEP NP), 2009, 33(3): 232-235
