Design and simulation of a new type of 500 MHz single-cell superconducting RF cavity

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper illustrates the design and simulation of a unique 500 MHz single-cell superconducting radio frequency cavity with a fluted beam pipe and a coaxial-type fundamental power coupler. The simulation results show that the cavity has a high r/ Qvalue, a low peak surface field and a large beam aperture, so it can be a candidate cavity for high current accelerators. With the help of a fluted beam tube, almost all the higher order modes can propagate out of the cavity, especially the first two dipole modes, TE ₁₁₁and TM ₁₁₀, and the first higher monopole mode, TM ₀₁₁. The external quality factor of the coaxial fundamental power coupler is optimized to 1.2×10 ⁵, which will be useful when it is applied in the light source storage ring.
